2
2016/09
TABLE OF CONTENTS
SECTION PAGE
PRODUCT SPECIFICATIONS ................................................................................... 2
CALIFORNIA PROPOSITION 65................................................................................ 3
SAFETY GUIDELINES - DEFINITIONS ..................................................................... 3
POWER TOOL SAFETY ............................................................................................. 4
ADDITIONAL SAFETY RULES FOR DRILL PRESSES.............................................. 6
ELECTRICAL REQUIREMENTS AND SAFETY ........................................................ 8
TOOLS NEEDED FOR ASSEMBLY ........................................................................... 10
CARTON CONTENTS ................................................................................................ 10
KNOW YOUR DRILL PRESS ....................................................................... 12
GLOSSARY OF TERMS.............................................................................................. 13
ASSEMBLY AND ADJUSTMENTS ............................................................................. 14
OPERATION ............................................................................................................... 19
MAINTENANCE .......................................................................................................... 23
ACCESSORIES AND ATTACHMENTS ...................................................................... 23
TROUBLESHOOTING GUIDE ................................................................................... 24
PARTS LIST................................................................................................................. 26
WARRANTY................................................................................................................. 28
PRODUCT SPECIFICATIONS
To avoid electrical hazards, re hazards or damage to the tool, use proper circuit
protection. Use a separate electrical circuit for your tools. The drill press is wired at the
factory for 120 Volt operation. It must be connected to a 120 V, 3.2 AMP branch circuit
and use a 3.2 AMP time delay fuse or circuit breaker. To avoid shock or re, replace
power cord immediately if it is worn, cut or damaged in any way.
Printed in China
WARNING
!
MOTOR TABLE
Power Source .…. 120 V, 60 Hz, 3.2 A Size ................................. 7-5/8 in. x 6-1/2 in.
Speed (No load) .. 1720 RPM (194 x 165 mm)
Type .................... Induction BASE
Volts .................... 120 volts AC only Size .................................
12-1/2 in. x 7-5/16 in.
LAMP................... Yes
(319 x 186 mm)
Spindle Travel ..... 2 in. (50 mm) Chuck to Column ............
5 in. (127 mm)
Speeds (RPM) .... 610~2800 RPM Chuck to Base ................
16-9/64 in. (410 mm)
Chuck Size .......... 1/2 in. (12.7 mm)
Column Size ....... 1-7/8 in. (48 mm)
