KIT NO. PART NO. KIT NAME REF NO.
1
E109152
Kit, Gasket 4 - 12
2
E105879
Kit, Oil Fill Cap 13 - 14
3
E109153
Kit, Oil Sight Gauge 10 - 11
4
E108923SV
Kit, L2 Motor/Pump Assembly w/RH Exhaust 1 - 26, 29
5 E100794 Kit, Air Filter 29 - 31
6 E109422 Kit, 3/8" Copper Outlet Tube 31 - 33
7 E109423 Kit, 1/4" Copper Pressure Relief Tube 35 - 37
8 E109875 Kit, Wheel (replaces one wheel only) 42 - 45
Replacement parts and service are available from your nearest authorized Service
Center. If the need arises, contact Product Service as listed.
When consulting with a Service Center or Product Service, refer to the model
number and serial number located on the serial label of the compressor. Proof of
purchase is required for all transactions and a copy of your sales receipt may be
requested.
Record the model number, serial number, and date purchased in the spaces
provided below. Retain your sales receipt and this manual for future reference.
When needing service, please contact the nearest authorized Service Center or
call:
PRODUCT SERVICE
In U.S.A. or Canada
Toll-Free: 1-888-895-4549
Fax: 1-507-723-5013
PARTS LIST
Model No. Serial No. Date Purchased
PARTS AND SERVICE
NOTE: Any part/kit number field without a number is not available. Descriptions are provided for
reference only. The Kit Number column represents that the part being offered is available in a kit.
One of each part per kit will be offered.
