TABLE OF CONTENTS
PRODUCT SPECIFICATIONS
SECTION
PRODUCT SPECIFICATIONS.....................................................................................................................
CALIFORNIA PROPOSITION 65.................................................................................................................
SAFETY GUIDELINES - DEFINITIONS ......................................................................................................
POWER TOOL SAFETY..............................................................................................................................
MITER SAW SAFETY..................................................................................................................................
ELECTRICAL REQUIREMENTS AND SAFETY..........................................................................................
TOOLS NEEDED FOR ASSEMBLY............................................................................................................
CARTON CONTENTS.................................................................................................................................
KNOW YOUR COMPOUND MITER SAW...................................................................................................
GLOSSARY OF TERMS..............................................................................................................................
ASSEMBLY AND ADJUSTMENTS..............................................................................................................
OPERATION................................................................................................................................................
MAINTENANCE...........................................................................................................................................
TROUBLESHOOTING GUIDE.....................................................................................................................
ACCESSORIES AND ATTACHMENTS.......................................................................................................
REPLACEMENT PARTS LIST.....................................................................................................................
WARRANTY.................................................................................................................................................
PAGE
2
3
3
4
6
8
10
10
11
12
14
21
27
28
29
30
31
Motor ......................
Speed (no load).......
Double Insulated.....
Saw Blade ..............
Arbor Size...............
Dust Port Size.........
Bevel Range............
Miter Range.............
Weight.....................
120 V AC, 60 Hz, 15 A
3800 RPM
Yes
12 in (305 mm) 40T
Carbide-tipped
1 in. (25.4 mm)
1 1/4 in. (31.75 mm)
-3° - 48°
0° - 48° R & L
35.2 lbs (16 kg)
CUTTING CAPACITY (Dimensional lumber)
Cross Cut 0° x 0° .....................
Miter Cut 45° x 0°......................
Bevel Cut 0° x 45°.....................
Compound Cut 45° x 45°..........
MITER/BEVEL POSITIVE STOP ANGLES
Miter Detent Stops ...................
Bevel Positive Stops.................
4 x 6 in., 2 x 8 in.
(101.6 x 152.4 mm, 50.8 x 203.2 mm)
4 x 4 in. (101.6 x 101.6 mm)
2 x 6 in. (50.8 x 152.4 mm)
2 x 4 in. (50.8 x 101.6 mm)
0°, 15°, 22.5°, 31.6°, 45° , 48° R & L
-3°, 0°, 45°, 48°
WARNING
electrical circuit for your tools.
way.
2017/07
Printed in China
