PORTMAN EVO ELEMENT - Mode Pixel Fine; Rdm Data

EVO ELEMENT™
16 / 20
▪ MODE PIXEL FINE
DMX
CH
Parameter
Description
1)
Intensity Main
Source Ch.1
Pixel 1 HaloLED 8 bit dimmer 0 –
100%
2)
Intensity Main
Source Ch.1 fine
Pixel 1 HaloLED 16 bit dimmer 0 –
100%
3)
Ch. 1 Glow Red
Red 8 bit on glow pixel 1 0 – 100%
4)
Ch. 1 Glow Red fine
Red 16 bit on glow pixel 1 0 – 100%
5)
Ch. 1 Glow Green
Green 8 bit on glow pixel 1 0 –
100%
6)
Ch. 1 Glow Green
fine
Green 16 bit on glow pixel 1 0 –
100%
7)
Ch. 1 Glow Blue
Blue 8 bit on glow pixel 1 0 – 100%
8)
Ch. 1 Glow Blue
fine
Blue 16 bit on glow pixel 1 0 –
100%
9)
Ch. 1 Glow White
White 8 bit on glow pixel 1 0 –
100%
10)
Ch. 1 Glow White
fine
White 16 bit on glow pixel 1 0 –
100%
11)
Intensity Main
Source Ch.2
Pixel 2 HaloLED 8 bit dimmer 0 –
100%
12)
Intensity Main
Source Ch.2 fine
Pixel 2 HaloLED 16 bit dimmer 0 –
100%
13)
Ch. 2 Glow Red
Red 8 bit on glow pixel 2 0 – 100%
14)
Ch. 2 Glow Red fine
Red 16 bit on glow pixel 2 0 – 100%
15)
Ch. 2 Glow Green
Green 8 bit on glow pixel 2 0 –
100%
16)
Ch. 2 Glow Green
fine
Green 16 bit on glow pixel 2 0 –
100%
17)
Ch. 2 Glow Blue
Blue 8 bit on glow pixel 2 0 – 100%
18)
Ch. 2 Glow Blue
fine
Blue 16 bit on glow pixel 2 0 –
100%
19)
Ch. 2 Glow White
White 8 bit on glow pixel 2 0 –
100%
20)
Ch. 2 Glow White
fine
White 16 bit on glow pixel 2 0 –
100%
21)
Intensity Main
Source Ch.3
Pixel 3 HaloLED 8 bit dimmer 0 –
100%
22)
Intensity Main
Source Ch.3 fine
Pixel 3 HaloLED 16 bit dimmer 0 –
100%
23)
Ch. 3 Glow Red
Red 8 bit on glow pixel 3 0 – 100%
24)
Ch. 3 Glow Red fine
Red 16 bit on glow pixel 3 0 – 100%
25)
Ch. 3 Glow Green
Green 8 bit on glow pixel 3 0 –
100%
26)
Ch. 3 Glow Green
fine
Green 16 bit on glow pixel 3 0 –
100%
27)
Ch. 3 Glow Blue
Blue 8 bit on glow pixel 3 0 – 100%
28)
Ch. 3 Glow Blue
fine
Blue 16 bit on glow pixel 3 0 –
100%
29)
Ch. 3 Glow White
White 8 bit on glow pixel 3 0 –
100%
30)
Ch. 3 Glow White
fine
White 16 bit on glow pixel 3 0 –
100%
31)
Strobe Main Source
HaloLED strobe channel
32)
Strobe Glow
Glow strobe channel
33)
Colour wheel All
Glow
Glow virtual colour wheel on all
pixels
34)
Intensity Macro
Macro 8 bit dimmer 0 – 100%
35)
Macro
Macro select channel
36)
Macro speed
Macro speed channel
37)
Control
Fixture control channel
▪ RDM DATA
Manufacturer ID
01CCh
Model ID
00.10
Super Simple personality ID
01
Simple personality ID
02
Standard personality ID
03
Standard Fine personality ID
04
Pixel personality ID
05
Pixel Fine personality ID
06
Parameters supported:
Parameter ID
Operation supported
DISC_UNIQUE_BRANCH
discovery
DISC_MUTE
discovery
DISC_UN_MUTE
discovery
DEVICE_INFO
get
SUPPORTED_PARAMETERS
get
SOFTWARE_VERSION_LABEL
get
DMX_START_ADDRESS
get and set
IDENTIFY_DEVICE
get and set
DEVICE_MODEL_DESCRIPTION
get
MANUFACTURER_LABEL
get
DEVICE_LABEL
get and set
DMX_PERSONALITY
get and set
DEVICE_HOURS
get
