EVO ELEMENT™ is fully compatible with the P2 EVO™ fixture and its accessories (base, height adaptor, spigot and
cotter).
◼ PREPARATION FOR USE
AC power connection
Luminaire must be powered with 100-240V and 50/60Hz. This fixture will automatically detect the
alternating current frequency. To turn on the fixture, simply plug in the powerCON TRUE1 and set the
power switch to “ON”. Use only high quality 3 x 2.5 mm
2
or larger mains power cords. Inspect all the power
feed cables for damages before use. Make sure to always connect the fixtures to a protected circuit with an
appropriate electrical ground. Never connect the fixture to a dimmer plug, even if it supplies proper current.
Only qualified electricians following all known electrical regulations can install the fixtures.
Luminaire comes with a power input cord terminated with powerCON TRUE1 on one end and tube
connectors on the other end. Follow the rules from the table below to assemble the power plug to the wire:
