◼ DMX MODES
▪ MODE SUPER SIMPLE
DMX
CH
Parameter
Description
1)
Intensity Main
Source Ch.1
Pixel 1 HaloLED 8 bit dimmer
0 – 100%
2)
Intensity Main
Source Ch.2
Pixel 2 HaloLED 8 bit dimmer
0 – 100%
3)
Intensity Main
Source Ch.3
Pixel 3 HaloLED 8 bit dimmer
0 – 100%
4)
All Glow Red
Red glow 8 bit on all pixels 0
– 100%
5)
All Glow Green
Green glow 8 bit on all pixels
0 – 100%
6)
All glow Blue
Blue glow 8 bit on all pixels 0
– 100%
7)
All glow White
White 8 bit on all glow pixels
0 – 100%
8)
Strobe Main Source
HaloLED strobe channel
9)
Strobe glow
Glow strobe channel
▪ MODE SIMPLE
DMX
CH
Parameter
Description
1)
Intensity Main
Source Ch.1
Pixel 1 HaloLED 8 bit dimmer
0 – 100%
2)
Intensity Main
Source Ch.2
Pixel 2 HaloLED 8 bit dimmer
0 – 100%
3)
Intensity Main
Source Ch.3
Pixel 3 HaloLED 8 bit dimmer
0 – 100%
4)
Intensity Glow
RGBW
RGBW Glow All pixels 8 bit
dimmer 0 – 100%
5)
All Glow Red
Red 8 bit on all glow pixels 0
– 100%
6)
All Glow Green
Green 8 bit on all glow pixels
0 – 100%
7)
All glow Blue
Blue 8 bit on all glow pixels 0
– 100%
8)
All glow White
White 8 bit on all glow pixels
0 – 100%
9)
Strobe Main Source
HaloLED strobe channel
10)
Strobe Glow
Glow strobe channel
11)
Colour wheel All
Glow
Glow virtual colour wheel on
all pixels
12)
Intensity Macro
Macro 8 bit dimmer 0 – 100%
13)
Macro
Macro select channel
14)
Macro speed
Macro speed channel
15)
Control
Fixture control channel
▪ MODE STANDARD
DMX
CH
Parameter
Description
1)
Intensity Main
Source Ch.1
Pixel 1 HaloLED 8 bit dimmer
0 – 100%
2)
Intensity Main
Source Ch.2
Pixel 2 HaloLED 8 bit dimmer
0 – 100%
3)
Intensity Main
Source Ch.3
Pixel 3 HaloLED 8 bit dimmer
0 – 100%
4)
Intensity Glow
RGBW
Dimmer 8 bit of RGBW Glow
0 – 100%
5)
Ch.1 Glow Red
Red 8 bit on glow pixel 1 0 –
100%
6)
Ch.1 Glow Green
Green 8 bit on glow pixel 1 0
– 100%
7)
Ch.1 Glow Blue
Blue 8 bit on glow pixel 1 0 –
100%
8)
Ch.1 Glow White
White 8 bit on glow pixel 1 0
– 100%
9)
Ch. 2 Glow Red
Red 8 bit on glow pixel 2 0 –
100%
10)
Ch. 2 Glow Green
Green 8 bit on glow pixel 2 0
– 100%
11)
Ch. 2 Glow Blue
Blue 8 bit on glow pixel 2 0 –
100%
12)
Ch. 2 Glow White
White 8 bit on glow pixel 2 0
– 100%
13)
Ch. 3 Glow Red
Red 8 bit on glow pixel 3 0 –
100%
14)
Ch. 3 Glow Green
Green 8 bit on glow pixel 3 0
– 100%
15)
Ch. 3 Glow Blue
Blue 8 bit on glow pixel 3 0 –
100%
16)
Ch. 3 Glow White
White 8 bit on glow pixel 3 0
– 100%
17)
Strobe Main Source
HaloLED strobe channel
18)
Strobe Glow
Glow strobe channel
19)
Colour wheel All
Glow
Glow virtual colour wheel on
all pixels
20)
Intensity Macro
Macro 8 bit dimmer 0 – 100%
21)
Macro
Macro select channel
22)
Macro speed
Macro speed channel
23)
Control
Fixture control channel
