Service manual Jetstream Mk3 - V. 1.0 - 11-02-08 Approved by: JN
JETSTREAM Mk3
EXPLODED VIEW & PARTS LIST- FIRST STAGE 0110-000
Item # Description
Qty
0012-028 (1007) O-ring, 1
4778 Conn. stem 1.stage 90 Xstream 1
4552 Cup type filter long Xstream 90 1
0010-354 (2918) O-ring 3
6010-233 Line protector Xstream, black 1
4754-5IP Housing 1.stage 1
4555 Spring for ball Xstream 1
0000-149 Ruby ball 1.stage Xstream 1
0015-059 (4557) O-ring 1
4758 Zytel valve seat Xstream 1
4760 Valve seat holder Xstream 1
4761 Valve seat spring Xstream 1
4777 Lower pin guide Xstream 1
4563 Pin bushing 1.stage Xstream 1
0015-012 (4423) O-ring 1
4762 Upper pin guide Xstream 1
4559 Actuating pin, Xstream 1
4564 Roll.diaphragm 1.stage Xstream 1
4565 Pressure plate 1.stage Xstream 1
4766 Adjust. spring 1.stage Xstream 1
4570-BK Barrier 1.stage Xstream, black 1
0000-140 Cover Xstream 1st stage, satin 1
4568 Screw cover M3x10 Xstream 3
4798-CH Adjustment screw, chrome 1
2680 Blindscrew UNF7/16 2
2679 Blindscrew UNF3/8 5
0010-353 (2782) O-ring 5
4576 BK Wheel G5/8” Xstream, black 1
3726 Valve sealing 1
3725 Valve piston 1
1180 Pressure spring 1
3727 Locking screw 1
