Page 49
Figure 2-15. General Pre-Dive Checklists.
Check that the battery is charged.
Inspect electronics module, handset,
cables, electric connections, HUD,
pneumatics hoses and oxygen sensors.
Mount top plate on top of scrubber,
check O-rings (2 O-rings).
Mount end plate in the bottom of
scrubber, check O-rings and sponge
(3 O-rings).
Install scrubber into cartridge housing,
tighten the four screws by hand.
Attach BC and harness to cartridge
housing.
Mount counterlungs.
Check valve.
Check hoses, mouthpiece, T-valves
and attach.
Check pressure, analyze, and attach
lled gas cylinders.
1
2
3
4
5
6
7
8
9
10
Pre-dive checklist
O2__________%__________psi/bar
Diluent_________%__________psi/bar
Helium_________%__________psi/bar
Attach electronics module, tighten the
two screws by hand.
Mount the two rst stages.
Attach IP diluent supply hose to
mouthpiece, tighten.
Attach HUD on to mouthpiece.
Attach IP diluent supply hose to inator.
Close OPV on right counterlung.
Negative loop pressure test.
Insert smart battery and conduct power-
up self-tests (see Start up procedure).
Prebreathe. It is very important to pre-
form a full prebreathe for a minimum of
5 minutes, while pinching your nose.
11
12
13
14
15
16
17
18
19
20
Check for damage, dirt and
deteriorations during assembly.
Poseidon SE7EN Pre-dive checklist
Figure 2-14. General Start up and Post-Dive Procedure.
Cylinders OFF, CLOSE OPV,
OPEN-CIRCUIT mode.
Touch wet-switch, keep dry for 5
seconds, then HOLD wet-switch.
Test 44, 45: turn cylinders ON.
Test 50: CLOSED-CIRCUIT.
Test 54: OPEN-CIRCUIT,
test bailout regulator function.
Test
1-38,55
40
43,50,54
44,45
48
49
53
Conrm and Restart
Needs Servicing (if persistent)
Use correct battery
Verify mouthpiece position
Turn cylinders on / Rell cylinders
Recharge Battery / Replace battery
Counterlungs half-full or less
Verify Oxygen Sensors
1
2
3
4
5
Start up Procedure
Mouthpiece in OPEN-CIRCUIT.
Both cylinders OFF.
Wet-switch DRY.
Purge ADV.
1
2
3
4
Post-Dive Procedure
