position ECS5000 - Installation with Accessories Surface Mount Versions; Installation with Base for Glass Door

EN
ECM5000 - ECM5000M - ECS5000 - ECS5000M - ECS8000 - ECS8000M
Surface mount or Mortice Electromagnetic locks
6 position.eu.com
7] INSTALLATION WITH ACCESSORIES SURFACE MOUNT VERSIONS
Electromagnetic lock
Z3Z4Z5
L3L4
Armature
plate
Door
Door
Adjustable
UBKP
Inward opening door (Pull door)
(installed with “UBKP”, “L3L4”
and Z3Z4Z5 brackets)
Installation with base
for glass door
Electromagnetic
lock
Universal
base for
glass door
UBKP
UBKP
Rubber washer
Steel washer
Armature
plate
Armature
screw
Roll pin
OUTDOOR
“Z” bracket
Z3Z4Z5
“L” bracket :
- L3L4 (300 - 400 Kg),
- L5 (500kg).
Steel washer
Roll pin
Armature plate
Roll pin
Screw
Screw
Joggle bracket
Joggle bracket
Armature screw
MORTICE VERSIONS: ECM5000 AND ECM5000M
INSTALLATION MANUAL
