position ECS5000 - Package Contents; Optional Accessories

EN
ECM5000 - ECM5000M - ECS5000 - ECS5000M - ECS8000 - ECS8000M
Surface mount or Mortice Electromagnetic locks
INSTALLATION MANUAL
3position.eu.com
3] PACKAGE CONTENTS
4] OPTIONAL ACCESSORIES
Surface mount
magnetic lock
Armature
plate
Fixing
plate
Roll pin
5x16
Steel
washer
Rubber
washer
4x25
wood screw
Key
3mm
1 1 1 2 2 4 7 1
Key
5mm
M8x35
screw
M8x25
screw
3x8
self-tapping
screw
Guide piece
Cap
nut
Installation
manual
1 1 1 1 1 1 1
Mortice
magnetic lock
Armature
plate
Joggle
bracket
Roll pin
5x16
Steel
washer
Rubber
washer
M5x8
screw
1 1 2 2 2 2 10
Key
5mm
M8x35
screw
Guide
piece
Cap
nut
Installation
manual
1 1 1 1 1
SURFACE MOUNT MORTICE
References
L3L4 (300KG)
L5 (500KG)
Z3Z4Z5 UBKU UBKP
AMA3 (300KG)
AMA5 (500KG)
DPM300
DPM500
AMCCHANFR16
AMCCHANFR20
Description
“L”
bracket
for lock
“Z”
bracket
for lock
Armature
base for
glass door
Universal
base for
glass door
Armature
base
Door
position
monitoring
Armature
mounting plate
MORTICE VERSIONS: ECM5000 AND ECM5000M
SURFACE MOUNT VERSIONS: ECS5000, ECS5000M, ECS8000 AND ECS8000M
