ECM5000 - ECM5000M - ECS5000 - ECS5000M - ECS8000 - ECS8000M
Surface mount or Mortice Electromagnetic locks
INSTALLATION MANUAL
6] INSTALLATION
SURFACE MOUNT VERSIONS: ECS5000, ECS5000M, ECS8000 AND ECS8000M
5position.eu.com
Electromagnetic lock
Armature plate
M8
screw
Cap nut
Guide piece
Rubber washer
Roll pin
Steel washer
Rubber washer
Fixing plate
Door frame
Electromagnetic
lock
Armature
plate
Cap nut
Guide piece
M8 screw
Door
Installation on an outward opening
door (Push door)
Outward opening
door (push door).
OutDOOR
INDOOR
Electromagnetic lock
Armature plate
Adjustable
(installed with “Z” and “L” brackets)
“Z” bracket :
Z3Z4Z5
“L”bracket :
“L” bracket
“Z”
bracket
Installation on an inward opening
door (Pull door)
Surface
mount lock
Rubber washer
Roll pin
Steel washer
Armature plate
M8 screw
Door frame
OUTDOOR
INDOOR
