I Series User’s Manual Chapter 3: Operations and Settings
5
Figure 3
1. Platen Roller 5. Bolt 9. ESD Brush
2. Printhead Module 6. Positioning Arm – Media Roll 10. Lever
3. Ribbon Supply Spindle 7. External Media Loading Opening 11. Media Sensor Cover Plate
4. Ribbon Take-up Spindle 8. Media Spindle
4
6
5
8
10
11
1
3
7
2
9
