- 07 -
Battery
Propellers Installation
When the aircraft's power is too low, it should land in time and the battery be charged.
As shown in the Picture, connect the adapter correctly to charge the battery. When
charging, the indicator lights red, and after full charging, the indicator lights green.
The charging time is about 2 hours.
Note
1. Please use the original charger to charge the battery.
2. Do not charge on a carpet to avoid fire.
3. Recharge every 3 months to keep battery active.
4. Do not put a charged battery under high temperature, such as open fire or electric heating device,
otherwise it will be damaged or exploded.
5. Do not strike or knock surface of hard objects with a battery.
6. Do not disassemble a battery.
7. Do not leave the battery alone during charging.
1. Hold the arm of the machine with your left hand, and pull out the 3 fixed points of the blade
guard in turn with your right hand (Figure 1)
2. Use the tool to disassemble the propellers (Figure 2)
Figure1 Figure2
Figure 3
Camera
3. There are two types of blades, choose the corresponding A blade or B blade (Figure 3)
4. Align the corresponding blade with the motor shaft and press down firmly, the blade
replacement is completed.
B
B
A
A
