Potter PS10 Series User Manual

MFG. #5401162 - REV C-1
12/10
PRINTED IN USA PAGE 4 OF 8
MODEL PS10 (VDS)
PRESSURE SWITCH
Engineer/Architect Specications Pressure Type Waterow Switch
Pressure type waterow switches; shall be a Model PS10 as
manufactured by Potter Electric Signal Company, St. Louis MO.,
and shall be installed on the re sprinkler system as shown and or
specied herein.
Switches shall be provided with a ½” NPT male pressure connection
and shall be connected to the alarm port outlet of; Wet Pipe Alarm
Valves, Dry Pipe Valves, Pre-Action Valves, or Deluge Valves.
The pressure switch shall be actuated when the alarm line pressure
reaches 0,27 - 0,55 BAR (4 - 8 PSI).
Pressure type waterow switches shall have a maximum service
pressure rating of 17,2 BAR (250 PSI) and shall be factory adjusted
Ordering Information
Model Description Stock No.
PS10-1 Pressure switch with one set SPDT contacts 1320011
PS10-2 Pressure switch with two sets SPDT contacts 1320021
Hex Key 5250062
Cover Tamper Switch Kit 0090200
to operate on a pressure increase of 0,27 - 0,55 BAR (4 - 8 PSI).
Pressure switch shall have one or two form C contacts, switch
contact rating 10.1 Amps at 125/250 VAC, 2.0 Amps at 30 VDC.
Pressure type waterow switches shall have two conduit entrances
one for each individual switch compartment to facilitate the use of
dissimilar voltages for each individual switch.
The cover of the pressure type waterow switch shall be Zinc die-
cast with rain lip and shall attach with one tamper resistant screw.
The Pressure type waterow switch shall be suitable for indoor or
outdoor service with a NEMA 4/IP66 rating.
The pressure type waterow switch shall be UL Ulc and CSFM
listed, FM and LPC approved and NYMEA accepted.

Potter PS10 Series Specifications

General

Brand	Potter
Model	PS10 Series
Category	Switch
Language	English
