SECTION 4 POTTERTON COMMERCIAL PRODUCTS DIVISION
INSTALLATION , OPERATION AND MAINTENANCE MANUAL
PAGE 16
PARAMOUNT
Table 3 Guide Values for Injector Pressure (full load)
Model Paramount 40 Paramount 60 Paramount 80
Nominal heat input kW 9.0 – 38.0 14.0 – 58.0 20.0 – 77.0
Nominal heat output 80/60°C kW 8.7 – 36.8 13.5 – 56.2 19.2 – 74.6
50/30°C kW 9.6 – 39.0 14.9 – 59.5 21.3 – 79.1
Injector for:
Natural Gas E (G20) mm 7.8 8.5 7.8
LPG (propane) mm 5.8 6.2 6.2
Type of gas: Guide values for injector pressure**
G20 (15,0)* mbar 6.0 – 6.6 6.0 – 7.0 11.0 – 12.5
Propane mbar 6.0 – 6.6 8.0 – 9.0 12.0 – 13.5
* Values in parenthesis = Wobbe index Won in kWh/m³
** At pressure at end of boiler 0 mbar, 1013 hPa, 15°C the CO
2
content should be
- between 8.3 and 8.8% for natural gas
- between 9.5 and 10.0% for LPG
OPERATING MODES
Table 4 Operating modes (operation with outdoor temperature sensor)
Operation With Room Temperature
Setting
Hot Water Temperature
Setting
Heating Program
Room control module RRG
1
) On room control module
RRG
On room control module
RRG
On room control module
RRG
Heating circuit module HKM
2
)
with timer
On heating circuit
module HKM heater
control
On heating circuit
module HKM hot water
control
On EMS or DSU timer
Heating control module HKM
with room thermostat
On room thermostat
RAV, RTD or RTW
(HKM heater control
must be set to max.
position)
On heating circuit
module HKM hot water
control.
On room thermostat
RAV, RTD or RTW
1) On mixed heating systems (application example 2) the room temperature setting applies for the constant and
variable temperature circuit.
2) On separate heating systems (application example 3) the room temperature setting on the heating circuit
module HKM applies for the CT heating circuit. The room and hot-water temperature setting on the room
control module RRG applies for the VT heating circuit.
