Potterton Paramount 40 - Section 1: Boiler Dimensions and Data; Paramount 40 General Data

POTTERTON COMMERCIAL PRODUCTS DIVISION
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
SECTION 1
PARAMOUNT
PAGE 1
Fig 1 – General Data and Dimensions Paramount 40
288
913
852
480
883
130
Ø125
407
Model
Paramount
HF – Flow 1”
HR – Return 1”
Gas – Gas Connection ¾”
SIV – Safety Valve ¾”
KA – Condensate Drain Ø25 mm
Gas
HR
HF
50
260
192
SIV
KA
116
A
A
Z
Z
A
A
Z
Z
Non Return valve
Paramount 40
only
NRV inoperative
Flow in any
direction
NRV operative
Flow to boiler
only
A
A
Z
Z
A
A
Z
Z
