Potterton Paramount 40 - Technical Data Table

POTTERTON COMMERCIAL PRODUCTS DIVISION
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
SECTION 1
PARAMOUNT
PAGE 3
Table 1 – Technical Data
Model Paramount 40 Paramount 60 Paramount 80
CE Number
0085BL0514
VDE Reg No.
137392G
Nominal Heat Input Range (net) kW
9.0 – 38.0 14.0 – 58.0 20.0 – 77.0
Nominal Heat Input Range (gross) kW
10.0 – 42.2 15.5 – 64.4 22.2 – 85.5
Nominal Heat Output Range 80/60°C kW
8.7 – 36.8 13.5 – 56.2 19.2 – 74.6
Nominal Heat Output Range 50/30°C kW
9.6 – 39.0 14.9 – 59.5 21.3 – 79.1
Gas Consumption (NG) m
3
/hr
4.0 6.0 8.0
Gas Consumption (LPG) m
3
/hr
1.61 2.46 3.21
Flue Temperature 80/60°C °C
67 64 66
Flue Temperature 50/30°C °C
50 48 48
Flue Gas Volume (15°C & 1013mbar Pressure) m
3
/hr
53.4 81.7 108.4
Nominal Gas Inlet Pressure (NG)
20 mbar
Gas Inlet Pressure (LPG)
Min 35mbar – Max 45 mbar
CO
2
for Natural Gas
8.3 – 8.8
CO
2
for LPG
9.5 – 10.0
Ventilation to BS5440 cm
2
155 245 N/A
High Level Ventilation to BS6644 cm
2
N/A N/A 191.25
Low Level Ventilation to BS6644 cm
2
N/A N/A 382.5
Hydraulic Resistance at 11°C ∆t
kPa
39 25.4 27
Hydraulic Resistance at 20°C ∆t
kPa
15 8.4 9.0
Water Flow at 11°C ∆t
lit/sec
0.80 1.22 1.67
Minimum Water Flow at 20°C ∆t
lit/sec
0.44 0.67 0.92
Cold Feed Size mm
19 19 25
Open Vent Size mm
25 25 32
Max Pressure at Boiler Flue Outlet mbar
1.1
Combustion Air/Flue Connection
Size
mm
125/80 150/110 150/110
Electrical Supply V/Hz
230/50
Maximum Electrical Power
Consumption
W
Amps
60
0.26
75
0.3
105
0.45
Minimum Operating Pressure Bar
1
Maximum Water Pressure Bar
3 4 4
Maximum Flow Temperature °C
85
Boiler Weight kg
58 63 76
Water Content lit
3.6 4.7 5.8
Boiler Height mm
852
Boiler Width mm
480
Boiler Depth mm
407 447 542
