DIMENSIONS
A

600mm
B

280mm
C

390mm
D

150mmØ
Min.
E

162.5mm
F 96mm
The1.5°fallprovidedbytheelbowistoallowcondensatetorunbacktotheboiler,fordisposalthroughthecondensatedischargepipe.
Fig.7
SIDEFLUE(leftandright)
Forevery1mofhorizontalfluelength,theclearanceabovethetopoftheflueelbow
shouldbe27.5mmtoincorporatethe1.5°fallinthefluefromtheterminaltotheelbow.
Fluelength(Y) Clearance(X)
upto1m 27.5mm
1m2m 55mm
2m3m 82.5mm
Fig.8
page11
6.0SystemDetails
6.1WaterCirculatingSystems
1.Theapplianceissuitableforusewithopenventfullypumpedsystemsandsealedsystems.
Thefollowingconditionsshouldbeobservedonallsystems:
Thestaticheadmustnotexceed30m(100ft)ofwater.
Theboilermustnotbeusedwithadirectcylinder.
Draincocksshouldbefittedtoallsystemlowpoints.
Allgasandwaterpipesandelectricalwiringmustbeinstalledinawaywhichwouldnotrestricttheservicingoftheboiler.
Positionisolatingvalvesasclosetocirculatingpumpaspossible.
Itisrecommendedthatthereturnpipeisfittedwithanautomaticairventasclosetotheboilerasispractical.
6.2TreatmentofWaterCirculatingSystems
Allrecirculatorywatersystemswillbesubjecttocorrosionunlessanappropriatewatertreatmentisapplied.Thismeansthatthe
efficiencyofthesystemwilldeteriorateascorrosionsludgeaccumulateswithinthesystem,riskingdamagetopumpandvalves,
boilernoiseandcirculationproblems.
Whenfittingnewsystemsfluxwillbeevidentwithinthesystem,whichcanleadtodamageofsystemcomponents.
