Pottinger SERVO 25 - Hydraulic Connection; Preparations on the Plough

0600-GB ANBAU_987
GB
ATTACHING TO THE TRACTOR
- 7 -
Hydraulic connection
1 Double-action control unit
Preparations on the plough
Mounting axle 825 mm
• Carry out adaption to the tractor´s lifting gear
- both helical plates can be fitted in 4 different positions (P1, P2,
P3, P4)
Upper link pins
Position upper link pins (6) as per diagram
- secure with linch pin (K).
6
161-02-25
K
