HANDLE HEIGHT ADJUST
5
The handle height is pre-set to suit most users but can be adjusted to one of ve positions. You only have to adjust
this once. To adjust:
1. With the trolley fully open, remove the locking bolt from the height adjust plate using the 4mm hex key supplied
in your manual pack.
2. Raise or lower the handle to the new desired position.
3. Tighten the bolt back up ensuring the adjustment plates on both sides are aligned and locked into the mating
features.
FRONT CASTER WHEEL ADJUSTMENT
6
Your trolley is pre-set to run straight but if your trolley is running o course,
adjust by:
1. Release the front wheel lever.
2. Rotate the front caster wheels 180 deg to expose the adjustment screws.
3. Using the hex key provided, adjust the two screws to angle the wheels.
Next to each wheel there is an indicator on the underside to help with
adjustment.
4. Once you are happy the trolley is running straight re-apply the lever to
lock in position.
