SD700 – PROFIBUS
POWER ELECTRONICS
20
INSTALLATION AND CONNECTION
3.4. Setting of Profibus Network Parameters
To set the Profibus address of the SD700 it is necessary to access to
G20.2 PROFIBUS. Please, push “*” key to go into this group.
Changing the value in parameter G20.2.1 we will set the address for
the slave, the address range is from 1 to 255, both included.
As soon as the optional board is connected to the drive the software
will recognize it and the following parameters will be available:
Parameter
Description
Range
Function
Set to Run
Modbus
Address
1 NODE
ADDR=10
NODE
ADDRESS
G20.2.1 /
Profibus
address
OFF=01
– 255
Setting of the Profibus address assigned to the
equipment in the network of the user. This address
must be provided by the network administrator of
the own user.
YES
40852
