4.3.4. Profipower SD700 Type 4 Module
This is also a pre-defined module, although broader than the
previous one. A high number of Modbus registers for reading and
writing has been defined. User only must write the value of the
registers.
Pre-defined registers for these modules are shown in the attached
table.
The Profibus board receives 54 bytes of output data of the Profibus-
DP Master.
Output
Data
(Word)
Param.
Modbus
Address
Variables
Range
Modbus Range
0
G3.3
40124
LOCAL_SPEED_REF
-250 to +250%
-20480 to + 20480
1
-
40562
HOST_START_CONTROL
0 to 1
0 to 1
2
-
40563
HOST_STOP_CONTROL
0 to 1
0 to 1
3
-
40564
HOST_RESET_CONTROL
0 to 1
0 to 1
4
-
40565
HOST_TRIP_CONTROL
0 to 1
0 to 1
5
G10.1
40102
LIMIT1_MIN_SPEED
-250 to Max Speed 1
-20480 to G10.2
6
G10.3
40103
LIMIT2_MIN_SPEED
-250 to Max Speed 2
-20480 to G10.4
7
G10.2
40104
LIMIT1_MAX_SPEED
Min. Speed 1 to +250%
G10.1 to 20480
8
G10.4
40105
LIMIT2_MAX_SPEED
Min. Speed 2 to +250%
G10.3 to 20480
9
G10.5
40106
CURRENT_LIMIT
0.25 to 1.50In, OFF
2048 to 12291
10
G10.9
40107
TORQUE_LIMIT
0% to +250%
0 to +20480
11
G10.11
40108
INVERTED_SPEED_ENABLED
Y/N
0 to 1
12
G2.1
40282
NAMEPLATE_MOTOR_CURRENT
1 to 9999A
1638 to 12288
13
G2.3
40285
NAMEPLATE_MOTOR_POWER
0 to 6500kW
0 to 65000
14
G5.1
40392
ACCELERATION_RATE
0.01 to 650% / sec
1 to 65000
15
G5.3
40393
ALT_ACCELERATION_RATE
0.01 to 650% / sec
1 to 65000
16
G5.2
40394
DECELERATION_RATE
0.01 to 650% / sec
1 to 65000
17
G5.4
40395
ALT_DECELERATION_RATE
0.01 to 650% / sec
1 to 65000
18
G5.5
40396
ACC_BRAKE_SPEED
OFF; 0 to 250%
0 to 20480
19
G5.6
40397
DEC_BRAKE_SPEED
OFF; 0 to 250%
0 to 20480
20
G10.6
40453
CURRENT_LIMIT_TIMEOUT
0 to 60s, OFF
0 to 600; 610
21
G11.2
40454
STOP_TIMEOUT
OFF=0.0 to 999s
0 to 9999
22
G10.10
40455
TORQUE_LIMIT_TIMEOUT
0 to 60s, OFF
0 to 600; 610
23
G11.4
40457
SUPPLY_UNDER_VOLTAGE
323 to 425V
586 to 621V
400V3230 to 4250V
690V5860 to 6210V
24
G11.6
40459
SUPPLY_OVE_VOLTAGE
418 to 587V
726 to 759V
400V4180 to 5870V
690V7260 to 7590V
25
G10.7
40109
CURRENT_LIMIT
0.25 to 1.50In, OFF
2048 to 12291
26
G10.15
41866
TORQUE_LIMIT
0% to +250%
0 to +20480
