4.3.5. Profipower SD700 Type 5 Module
For this module it can be defined up to 10 Scenarios, 5 for the write
command and the other 5 for the read command. This module is
specific for the SD700 drive; therefore, the Profibus board will be set
up with the valid Modbus address for the SD700. User only must
select the available Modbus registers.
The defined frames for this module are: 20 bytes of Data-Output and
20 bytes of Data-Input.
Therefore, the maximum number of selected Modbus registers will
be 10 for the writing Scenarios and 10 for the reading Scenarios.
That is, all the registers selected for the configured writing Scenarios
do not exceed 10. And in the same way, all the registers selected for
the configured reading Scenarios do not exceed 10.
The description of the Profibus frame will be determined by the
realized set up of the scenarios.
