8717621 302cc OHV Winter Gas Engine V4.0
2 For technical questions call 1-800-665-8685
SPECIFICATIONS
Displacement 302cc
Torque 13.64 ft-lb
Max. Speed 3,600 RPM
Shaft Diameter 1 in.
Shaft Rotation CCW
Shaft Length 3.5 in.
Shaft End Tapped (Diameter (in) / Threads Per Inch) 7/16-20 UNF
Fuel Type Gasoline
Fuel Tank Capacity 6.3 Quarts
Fuel Filter Yes
Oil Capacity 1.01 Quarts
Lubrication System Splash
Low Oil Alert No
Low Oil Shutdown Yes
Start Type Pull Recoil/110V AC
Ignition System Transistorized Magneto
Governor System Mechanical
Number of Cylinders 1
Bore Diameter 3.15 in.
Stroke 2.36 in.
Compression Ratio 8.5:1
Muffler Yes
Spark Plug SKU# 4780112
Tune Up Specifications
Spark Plug Gap
0.7 ~ 0.8 mm (0.028 ~ 0.031 in.)
Spark Plug Torque
18 ~ 22 N-m
0.08 ~ 0.12 mm (0.0031 ~ 0.0047 in.)
Exhaust Valve Clearance
0.13 ~ 0.17 mm (0.0051 ~ 0.0067 in.)
INTRODUCTION
The 302cc OHV Winter Gas Engine features both an 110V electric ignition and recoil pull starter. The engine speed
can be controlled with a handle throttle connected via the included throttle cable. The engine is protected by a
weather resistant cover and a low oil shutdown mechanism. The engine is ideal for snow blowers, agricultural or
forestry equipment.
302cc OHV
Winter Gas Engine
