6. Specifications of Switches and Sensors
6.1 Mechanical Switch
6.1.1 SPDT, SZM-V16-2FA-61
< SPDT Mechanical Switch>
Model
Non-Inductive Override Inductive override
Resistance Lamp Inductivity Motor
Allowed
voltage
250VAC
8VDC
30VDC
125VDC
250VDC
16A
16A
10A
0.6A
0.3A
2A
4A
4A
0.1A
0.05A
10A
10A
10A
0.6A
0.3A
3A
6A
4A
0.1A
0.05A
<Connection Di
agram>
Operating
Temperature
-30 ~ +105 ℃
6.1.2 Honeyw
ell SPDT, V7-1C17E9-022
< SPDT Mechanical Switch>
Model
Non-Inductive Override / Inductive override
Allowed
Voltage
125VAC
250VAC
277VAC
125VDC
250VDC
15.1A 1/2HP
15.1A 1/2HP
15.1A 1/2HP
0.5A
0.25A
<Connection Di
agram>
Operating
Temperature
-40 ~ +82 ℃
6.2 P&F Proximity Sensor NJ2-V3-N
<Proximity Sensor>
Standard Features
Swit
ching Functioning Factor
Detection Range
Installation
Output polarity
Certified Detection range
NAMUR NC
2mm
Built-in
NAMUR
0 ~ 1.62 mm
Nominal Ratings
Nominal voltage
Switching Frequency
Hysteresis
Power consumption
Measuring plate not detected
Measuring plate detected
8.2 VDC
0 ~ 1000 Hz
0.01 ~ 0.1 mm
> 3mA
< 1mA
<Connection Di
agram>
Mechanical property
Connection Type
Core Cross Section
Housing Material
Sensor Surface
Protection Rate
PCV Cable, 130 mm
0.14 mm
PBT
PBT
IP67
Operating Temperature -25 ~ +100 ℃
