Power-Genex LSB-1000 Series User Manual

LSB-1000 Series
jjautomation.com
8
3. Product Specifications
Product LSB-1000
Protection Rate Waterproof Dustproof IP67 (Option IP68)
Switch / Sensor
Mechanical Switch (2) SPDT, (4) SPDT
P&F Proximity Sensor (2)
NJ2-V3-N
Autonics Proximity Sensor (2)PSN17-5D
Honeywell Mechanical Switch (2)SPDT
Hermetically-sealed magnetic Sensor (2)MS-20
Operating Temperature -40 ~ +100℃ (-40 ~ +212℉)
Electrical Connections PF1/2, NPT 1/2, M20x1.5, PG13.5
Body Materials Aluminum Die-cast
Weight 0.8kg
• Non-Explosion-proof type (IP67 / IP68) Switch Box.
• Made with solid Aluminum Die-Casting Material
4. Nameplate
- Model: LSB-1000
- Switch
: Shows Switch / Sensor type.
- Ratings: Shows rated voltage / Current.
LSB-1000
Mechanical switch : 2 x SPDT
Ratings : 16A at 1/2HP 125/250VAC
0.6A 125VDC, 0.3A 250VDC
