5. Part Numbering System (order code)
LSB — 1 x x x — x x x x x x
0
Switch / Sensor
Mechanical
Switch
2 x SPDT 0
4 x SPDT 2
Prox
imity
Sensor
2 x NJ2-V3-N / P&F 4
2 x PSN17-5D (PNP or NPN)
Autonics
8
Honeywell
Sw
itch
2 x SPDT (Silver) J
2 x SPDT (Gold) L
Hermetically
Sealed
magnetic
Sensor
2
x MS-20 C
Position transmitter Not Included 0
Protection Rate Waterproof Dustproof IP67 7
Waterproof Dustproof IP68
8
Beacon
Indicator
Not Included N
Beacon Indicator 90° (open / close) A
L or T Port Indicator D
Electrical PF 1/2 C
Connections NPT 1/2 D
M20x1.5 E
PG 13.5 H
No. of Electrical
Connections
2 pcs 2
Feedback Shaft
Rotary
Type
NAMUR Shaft N
Fork Lever F
Linear
Ty
p
e
Stroke 10 ~ 40mm A
Stroke 10 ~ 80mm B
Stroke 80 ~ 150mm C
Stroke 80 ~ 200mm D
Mounting Bracket Non N
30 x 80 x 20(H) - VDI / VDE3845 (IEC60534-6-2) 1
30 x 80 x 30(H) - VDI / VDE3845 (IEC60534-6-2) 2
30 x 130 x 30(H) - VDI / VDE3845 (IEC60534-6-2) 3
30 x 130 x 50(H) - VDI / VDE3845 (IEC60534-6-2) 4
Multi-Size Bracket M
