Power integrations TOPSwitch-HX Series - Default Chapter; Table of Contents

Rev. J 08/16
3
TOP252-262
www.power.com
Section List
Functional Block Diagram ....................................................................................................................................... 4
Pin Functional Description ...................................................................................................................................... 6
TOPSwitch-HX Family Functional Description ....................................................................................................... 7
CONTROL (C) Pin Operation .................................................................................................................................... 8
Oscillator and Switching Frequency .......................................................................................................................... 8
Pulse Width Modulator ............................................................................................................................................ 9
Maximum Load Cycle .............................................................................................................................................. 9
Error Amplifier .......................................................................................................................................................... 9
On-Chip Current Limit with External Programmability ............................................................................................... 9
Line Undervoltage Detection (UV) ........................................................................................................................... 10
Line Overvoltage Shutdown (OV) ............................................................................................................................ 11
Hysteretic or Latching Output Overvoltage Protection (OVP)................................................................................... 11
Line Feed-Forward with DC
MAX
Reduction .............................................................................................................. 13
Remote ON/OFF and Synchronization .................................................................................................................... 13
Soft-Start ............................................................................................................................................................... 13
Shutdown/Auto-Restart ......................................................................................................................................... 13
Hysteretic Over-Temperature Protection ................................................................................................................. 13
Bandgap Reference ............................................................................................................................................... 13
High-Voltage Bias Current Source .......................................................................................................................... 13
Typical Uses of FREQUENCY (F) Pin ...................................................................................................................... 15
Typical Uses of VOLTAGE MONITOR (V) and EXTERNAL CURRENT LIMIT (X) Pins .......................................... 16
Typical Uses of MULTI-FUNCTION (M) Pin ........................................................................................................... 18
Application Examples .............................................................................................................................................. 21
A High Efficiency, 35 W, Dual Output – Universal Input Power Supply ..................................................................... 21
A High Efficiency, 150 W, 250-380 VDC Input Power Supply .................................................................................. 22
A High Efficiency, 20 W Continuous – 80 W Peak, Universal Input Power Supply ................................................... 23
A High Efficiency, 65 W, Universal Input Power Supply ........................................................................................... 24
Key Application Considerations .............................................................................................................................. 25
TOPSwitch-HX vs.TOPSwitch-GX ....................................................................................................................... . 25
TOPSwitch-HX Design Considerations .................................................................................................................. 26
TOPSwitch-HX Layout Considerations ................................................................................................................... 27
Quick Design Checklist .......................................................................................................................................... 31
Design Tools .......................................................................................................................................................... 31
Product Specifications and Test Conditions .......................................................................................................... 32
Typical Performance Characteristics .................................................................................................................... 39
Package Outlines .................................................................................................................................................... 43
Part Ordering Information ........................................................................................................................................ 47
