Safety Precautions
l Make sure the engine is off before you begin any maintenance or repairs. This will
eliminate several potential hazards:
n Carbon monoxide poisoning from engine exhaust.
Be sure there is adequate ventilation whenever you operate the engine.
n Burns from hot parts.
Let the engine and exhaust system cool before touching.
n Injury from moving parts.
Do not run the engine unless instructed to do so.
l Read the instructions before you begin, and make sure you have the tools and skills
required.
l To reduce the possibility of fire or explosion, be careful when working around gasoline.
Use only a nonflammable solvent, not gasoline, to clean parts. Keep cigarettes, sparks
and flames away from all fuel-related parts.
Remember that your servicing dealer knows your engine best and is fully equipped to
maintain and repair it.
To ensure the best quality and reliability, use only new, genuine parts or their equivalents
for repair and replacement.
MAINTENANCE SCHEDULE
l Emission-related items.
（1）These items should be serviced by your servicing dealer unless you have the proper
tools and are mechanically proficient. Refer to manual for service procedures.
REGULAR SERVICE PERIOD
Performed at every indicated month or
operating hour interval, whichever comes
first.
Each
use
First
month or
20 Hrs.
Every 3
months or
50 Hrs.
Every 6
months or
100 Hrs.
Every
year or
150Hrs.
ITEM
●
Engine oil
Check
level
○
Change
○ ○
●
Sediment Cup Clean
○
●
Spark plug
Check-Cle
an
○
Replace
○
●
Valve clearance
Check-Adj
ust
○(1)
●
Combustion
chamber
Clean
After every 150 Hrs. (1)
●
Fuel line Check
Every 2 years (Replace if necessary) (1)

Power smart 196cc Specifications

General

Type	Single cylinder, 4-Stroke, Forced Air Cooling, OHV
Bore×Stroke(mm)	68×54
Displacement(cc)	196
Net power(kW/3600rpm)	4.1
Net torque (N·m/rpm)	12.4/2500
Fuel consumption (g/kW·h)	≤395
Speed Fluctuating Ratio	≤10%
Compression Ratio	8.5:1
P.T.O shaft rotation	Anti-clockwise(from P.T.O. side)
Oil capacity(L)	0.6
Noise(≤)	70dBA
Lubricating mode	Splash
Starting Mode	Recoil start / Electric starting
Valve Clearance	input valve：0.10~0.15mm, output valve：0.15~0.20mm
Spark plug clearance	0.7~0.8mm
Igniting Mode	Transistorized magneto Ignition
Air cleaner	No filter

Weight and Dimensions

Dimension(L×W×H) (mm)	382×354×276
