Poweramp PR - Page 45

PARTS
43
4111-0001 — June 2003
Item Quantity Part Number Description
A 1 0522-0005 Clevis Pin
B 1 2101-0045 Cotter Pin
C 1 0522-0156 Yo k e
D 1 0521-0005 Roll Pin
E 1
0525-0086 Lip Cylinder, 13-3/4 in. (349 mm) Barrel Length
0525-0087 Lip Cylinder, 20-1/8 in. (511 mm) Barrel Length
F 1 9202-0004 Pin, 3/4 x 4.38 in.
G 2 2101-0049 Clip, Hairpin
H 1 9301-0111 Fitting, #6-ORB Male x #8-JIC Male
J 1 9904-____
1
Hose, Logic Block-to-Lip Cylinder
K 1 9904-____
1
Hose, Pump Pressure Port-to-Logic Block
L 2 2101-0015 Cap Screw, 5/16-18 UNC x 3-1/4 in.
M 2 2101-0039 Nylon Lock Nut, 5/16-18 UNC
N 1 9575-____
3
Logic Block
P 2 2101-0050 Clip, Hairpin
Q 2 9202-0005 Pin, 1 x 3-3/4 in.
R 4 2101-0009 Cap Screw, 5/16-18 UNC x 3/4 in.
S 2 7942-0006 Platform Cylinder, Hold Down
T
1 0525-0043 Cylinder, Platform, 15-1/2 in. (394 mm) Barrel Length
1 0525-0044 Cylinder, Platform, 17-1/2 in. (445 mm) Barrel Length
1 0525-0045 Cylinder, Platform, 19-1/2 in. (495 mm) Barrel Length
1 0525-0046 Cylinder, Platform, 21-1/2 in. (546 mm) Barrel Length
U 1 9301-0120 Elbow, 45° #8-ORB Male x #8-JIC Male
V 1 9904-____
1
Hose, Logic Block-to-Platform Cylinder
W 1 9904-____
1
Hose, Logic Block-to-Pump Return Port
X 2 2101-0040 Nylon Lock Nut, 3/8-16 UNC
Y 2 2101-0060 Washer, 3/8 in.
Z 1 9455-____
2
Hold-Down, Lip Cylinder
AA 1 0522-0002 Spring
AB 1 0521-0007 Elbow, 90° 1/4 NPT Male x 1/4 Tube
AC 2 2101-0011 Cap Screw, 5/16-18 UNC x 1 in.
AD 1 9395-____
3
Power Pack Complete
AE 1 0521-0016 Elbow, 45° 3/8 NPT Male x #8-JIC Male
AF 1 0521-0015 Straight Fitting, 3/8 NPT Male x #8-JIC Male
AG 6 2101-0039 Nylon Lock Nut, 5/16-18 UNC in.
AH 1 9392-0042 Mounting Bar
AJ 1 0521-0007 Elbow, 90° 1/4 NPT Male x 1/4 Tube
AK 4 2101-0011 Cap Screw, 5/16-18 UNC x 1 in.
AL 1 R509-____
1
Tube, Vent (3/8 OD x 1/16 in. Wall)
AM 1 0523-____
2
Lip Lifter
Hydraulic Components
1
Provide length and diameter of hose when calling or faxing orders.
2
Provide length of lip cylinder when calling or faxing orders.
3
Provide dock leveler serial number, voltage, and phase when calling or faxing orders.
