PARTS
44
4111-0001 — June 2003
Platform Cylinder Repair Parts
Item Quantity Part Number Description
A 1 0522-0120 Gland
B 1 0521-0104 Rod Step Seal
C 1 0521-0008 O-Ring
D 1 0521-0009 Backup Ring
E 1 0521-0103 Wear Ring (Slydring)
F 1 0521-0105 Excluder Plus Seal
G 1 0521-0013 Retaining Ring
H 1
0525-0043 Cylinder, Platform, 15-1/2 in. (394 mm) Barrel Length
0525-0044 Cylinder, Platform, 17-1/2 in. (445 mm) Barrel Length
J 1 1751-0138 Decal
1 0525-0013 Seal Kit (Includes Items A–G) *For cylinders made before 1992
1 0525-0048 Seal Kit (Includes Items A–G) *For cylinders made since 1992
*Provide dock leveler serial number when calling or faxing orders.
A
B
C
E
F
D
G
H
J
