OPERATION
Multi-Colored & Outside Light Sequence Charts
Condition
Lights
Inside Outside
Ready For Use Red Green
Leveler Operating or Restraint
Engaging/Releasing In Progress
Amber Red
Restraint Engaged Green Red
Restraint Engage Failure Red/Amber, Display Backlight* Red
Emergency Stop Active Red (solid)* Red (solid)
Normal Operation
Condition
Lights
Inside Outside
Restraint Engage Failure
(Bypass Mode prompt)
Red/Amber, Display Backlight Red
Bypass Mode
Green/Amber
(Green/Red on Dock Alert)
Red
Reset Attempted (Leveler in Use) Red/Amber, Display Backlight Red
Reset Attempted (Door Open) Green/Amber, Display Backlight Red
Reset Lights to Normal Mode Red, Display Backlight (5 seconds) Green
Bypass Mode
Condition
Lights
Inside Outside
Main Menu Active Red (solid) Red (solid)
System Fault Present Red/Amber Red
Restraint Use Disabled Amber None
Menu & Diagnostics
*If equipped, Audible Alarm will also be active.
