ADJUSTMENTS
Figure 19
Figure 20
45 DEGREES
96 IN-LBS
LOCKNUT
BRAKE ADJUSTER SET SCREW
USE TORQUE WRENCH
LUBRICATE DRIVE CHAIN AND LIMIT
SWITCH MOUNTING BRACKET. USE
SPRAY GREASE (ZEP 2000 OR EQUAL)
