35
4111-0035 — Dec. 2018
©
2018 Systems, LLC
TPR Carriage Assembly (continued)
PARTS
Item Quantity Part Number Description
1 2 2101-0126 SCREW,HHCS,3/8”-16 X 1-1/2”
2 3 2101-0321 SCREW,HHCS,5/16-18 X 5/8”
3 1 9701-0200 RING , SNAP
4 4 9701-0113 ROLLER ASSEMBLY
5 1 9701-0201 3/4” CONDUIT NIPPLE
6 1 0961-0570 LIMIT SWITCH, LS1
7 1 0961-0571 LIMIT SWITCH, LS2
8 1 9701-0112 CAM
9 2 9701-0111 BEARING ASSEMBLY
10 1 9701-0202 DECAL, CAM
11 1 9701-0109 LIMIT SWITCH MOUNTING PLATE
12 1 9701-0244 CHAIN COVER
13 2 9701-0203 LOCK NUT 7/16”-14 SERRATED FLANGE
14 8 9701-0204 NUT, LOCK 3/8”-16 SERRATED FLANGE
15 2 9701-0205 CAP SCREW 1/4”-20 X 1-1/2” SOCKET HEAD
17 2 9701-0206 BUSHING, MACHINERY 1-3/4” OD,1-1/4” ID,1/8”THICK
18 2 2101-0005 WASHER, LOCK 1/4”
20 1 9701-0207 KEY, HOOK 1/4” X 1/4” X 1-1/4”
21 2 9701-0208 KEY, SPROCKET/CAM 1/4” X 1/4” X 1”
22 1 9701-0110 HOOK SHAFT
23 2 9701-0209 NUT,LOCK 3/4” CONDUIT
24 1 9701-0114 DRIVE SPROCKET,HOOK W/SET SCREW
25 1 9701-0210 SCREW, SET 5/16”-18 X 1/2” SK
26 6 9701-0211 BOLT, CARRIAGE 3/8”-16 X 1”
27 1 9701-0212 CORD GRIP
28 1 9701-0107 STRAIGHT HOOK
29 1 9701-0106 CARRIAGE WELDMENT
30 1 4301-0008 WIRE HARNESS
31 1 9701-0115 CHAIN
32 1 3411-0050 MOTOR ASSEMBLY
33 1 1751-0847 DECAL, TPR
34 1 9701-0213 SCREW SET 5/16”-18 X 5/8”
36 1 1751-0851 DECAL, TPR STRIPE RH
37 1 1751-0850 DECAL, TPR STRIPE LH
38 1 9701-0214 NUT, NYLOCK 7/16”-14
39 2 9701-0215 GREASE FITTING
42 2 2101-0010 BOLT, 5/16-18 X 7/8 LG
43 4 2101-0322 SCREW,SHSS,1/4-28 UNF X 1/4 SOCKET CUP
44 2 2101-0010 SCREW,HHCS,5/16-18 UNC X 7/8
45 1 9701-0108 CHAIN COVER WITH MOUNTING HOLE
