20
• Remove any further blockage from the equipment.
• When fitting the cover
16
back on, ensure it is fitted correctly so that
the blade shaft
18
, the pressure plate rod
17
and the four recesses
15
for the Allen screws are all correctly aligned and fit smoothly into
the recesses on the cover. Ensure that the cutting pressure plate is
positioned correctly.
• Screw on the housing cover
15
firmly with the four Allen screws
14
.
16
17
18
14
15
Fig. 7
