16
WARNING! Use only original manufacturer’s replacement
parts, accessories and attachments. Failure to do so can
cause poor performance, possible injury and may void
your warranty. Never use the machine without the guard
assembled!
Assemble the Nylon cutting head
Release the nuts
Line up the two holes of the flange and shield. Using one screw
driver to hold the flange, as shown below, turn the socket wrench
clockwise until the nut is released.
A. Assemble the nylon cutting head
Remove another shield after the nut is released. Still holding
the flange, take the nylon cutting head on the shaft and rotate
counter-clockwise. The nylon cutting head is fitted.
B. Assemble the blade
Take the outer flange off after releasing the nut, then put the
blade, outer flange, shield and nut according to priority.
