16
Assemble the upper cover of the handle holder.
Assemble the lower shaft
Release the fasten bolt on the shaft connector.
Insert the lower shaft into the connector, make sure the stop
pin (a) on the shaft slots into the hole (b). Fasten the bolt on the
connector.
Assemble the safety guard
Put the guard onto the working head.
a
b
