17
Fix the guard with 4 screws and tighten the screws.
Assemble the brush cutter blade
Press the lock button (C) to fix the output shaft, then rotate the
nut in clockwise direction by the socket wrench.
Take the outer flange off after releasing the nut, then put the
blade, outer flange and nut according to priority.and fasten the nut
in anti-clockwise direction.
Assemble the trimmer spool
Disassemble the brusher cutter blade as well as the blade retainer.
Put the spool on the bolt, lock the flange and then fasten the
spool by anti-clockwise.
C
