POWERBOR PB70/2 - Page 12

PB70 Manual Original instructions May 2019
12
No.
Part
Description
Qty
1
RD23603
COOLANT BOTTLE ASSEMBLY
1
2
RD4269
M6×25 SOCKET CAP HEAD SCREW
1
3
RD4414
SCREW M4 X 10
2
4
RD33338
FIXED RATCHET WHEEL
1
5
W18XC209
SCREW
2
6
18Y3008
COOLANT BRACKET
1
7
18Y177
CONDUIT ASSEMBLY
1
8
W18XC723
GLAND AL16/M16/A
2
9
W18XC612
RETAINING BRACKET
1
10
W18Y172
MAIN BODY CASTING ASSEMBLY
1
11
W18XC502
20 X 20 X 15 BUSH (INCLUDED IN ITEM 10)
2
12
W18XC710
PB70 PINION
1
13+14
W18Y156
HANDLE & KNOB ASSEMBLY
1
15
W18XC220
M5 X 25 GRUB SCREW (INCLUDED IN ITEM 10)
7
16
W18XC219
M5 STEEL NUT (INCLUDED IN ITEM 10)
7
17
W18XC346
SHIM STRIP
1
18
18Y178/CS
CONTROL PANEL ASSEMBLY 110V
1
18
18Y179/CS
CONTROL PANEL ASSEMBLY 230V
1
19
W18XC716
BRASS GUIDE
2
20
W18XC201
M6 X 20 CAP HEAD
7
21
W18XC717
DOVETAIL SLIDE
1
22
W18XC201
M6 X 20 CAP HEAD
9
23
RDA3032
GUARD SUPPORT
1
24
W18XC214
M6 SCHNORR WASHER
2
25
RD4347
M5 X 15 C/SNK SKT HEAD SCREW
2
26
W18XC222
M6 X 50 CAP HEAD SCREW
1
27
W18Y102
MT3 COOLANT ARBOR
1
28
18Y3006
MOTOR SUPPORT BRACKET
1
29
RDA4021
M4×14 BUTTON HEAD SCREW
2
30
18Y3002
SLIDE CHANNEL
1
32
18Y3003
GUARD
1
33
W18Y173
MAGNET BASE ASSEMBLY
1
34
W18XC212
M6X10 LOW PROFILE CAP HEAD SCREW
1
35
W18XC6231
SIDE BRACKET
1
36
W18XC202
M6 X 25 CAP HEAD
6
37
W18XC227
M6 STEEL WASHER
2
38
W18XC1026
REAR PANEL PLATE
1
39
W18XC221
M5 X 16 SOCKET CAPHEAD
1
