7) EXTENSION CABLE SELECTION
The machines are factory fitted with a 2 metre length of cable having three conductors 1.5mm²
LIVE, NEUTRAL and EARTH. If it becomes necessary to fit an extension cable from the power source, care
must be taken in using a cable of adequate capacity. Failure to do so will result in a loss of traction by the
magnet and a reduction of power from the motor.
Assuming a normal AC supply of the correct voltage, it is recommended that the following extension lengths
shall not be exceeded:
For 110v supply: 3.5 yards of 3 core x 1.5mm²
For230v supply: 26 yards of 3 core x 1.5mm²
ALWAYS DISCONNECT THE MACHINE FROM THE POWER SOURCE BEFORE CHANGING CUTTERS.
8) MOUNTING OF CUTTERS
• The machine has been made to accept cutters having 19.05mm (3/4”) dia. Weldon shanks.
The following procedure is to be used when mounting cutters:
• Lay the machine on its side with feed handles uppermost, ensuring arbor is wound down to its lowest
point to enable access to socket screws.
• Take appropriate pilot and place through the hole in cutter shank. Insert shank of cutter into bore of
arbor, ensuring alignment of two drive flats with socket screws.
• Tighten both screws using hexagon key.
STAN OPERATION
