4
PowerBox-Systems − World Leaders in RC Power Supply Systems
1. FEATURES AND CONNECTIONS
2. INSTALLING AND CONNECTING THE BATTERIES
The PowerBox Sensor V3 should be installed in the model in a position where
vibration levels are low. Solid GRP fuselage sides in a power model should be tted
with an internal 3 – 4 mm thick plywood plate to minimise vibration, and to provide
‘meat’ for the retaining screws.
Connect the two batteries of your choice – with correct polarity – to the battery
inputs. You can use either two 2s LiPo or LiIon, two 2s LiFePo or two 5s NiMH
batteries. We recommend the use of PowerPak 2.5x2 Pro batteries, which are par-
ticularly safe and simple to handle thanks to their integral charge circuitry.
Push-button Battery sockets
(MPX or JR)
RGB LED
voltage and status
indicators
Receiver
outputs
