Powercom 1000A - Appendix A Troubleshooting; Appendix B Specifications

D:\manual\UM_PCM-BNT\661-BT1K-000.doc
- 7 -
A
PPENDIX A
T
ROUBLESHOOTING
PROBLEM POSSIBLE CAUSE ACTION TO TAKE
Power switch not pushed or
push-time too short
Press the power switch more
than 1 second
Battery voltage less than 20V Recharge the UPS at least 6
hours
PCB failure Replace the PCB, call for
service
UPS can not
turn on LED not
light
Load less than 20W at battery
mode
Normal condition, “No load
shutdown function” is active
(See 3.2)
Power cord lose Plug in the power cord
AC fuse burn out Replace the AC fuse or Breaker
Line voltage too high, too low
or black out
Normal condition
UPS always at
battery mode
PCB failure Replace PCB, call for service
battery not fully charged Recharge the UPS at least 6
hours
Back up time
too short
PCB failure Replace PCB, call for service
Buzzer
continuous
beeping
Overload Remove some loads
A
PPENDIX B
S
PECIFICATIONS
MODEL 1000A/AP 1500A/AP 2000A/AP
Capacity 1000VA 1500VA 2000VA
Voltage 100V,110V,115V,120V,220V,230V,240V, +/-25% at
line input
INPUT
Frequency 50 or 60Hz +/- 10% (auto sensing)
Voltage
(Backup mode)
Simulated sine wave like rating voltage, +/-5%
Frequency
(Backup Mode)
50 or 60Hz +/- 1Hz
Auto Voltage
Regulation (AVR
function under
Normal mode)
AVR automatically increase output voltage 15%
above input voltage if -9% to-25% of nominal.
AVR decrease output voltage 13% below input
voltage if+9% to +25% of nominal
OUTPUT
Transfer Time 2/4 milliseconds, including detection time
D:\manual\UM_PCM-BNT\661-BT1K-000.doc
- 8 -
Overload
Protection
UPS automatic shutdown if overload exceeds
110% of nominal at 60 seconds and 130% at 3
seconds
Unit Input Fuse for overload & short circuit protection
PROTECTION
And
FILTERING
Short Circuit UPS output cut off immediately or input fuse
protection
Type Sealed, maintenance-free lead acid
Typical
Recharge Time
4 hours
(to 90% of full capacity)
BATTERY
Back up Time
(PC with 15”
monitor)
60-70
minutes
70-80
minutes
80-90
minutes
Dimension(mm)
WxDxH
130x382x201
Input Inlet IEC 320 power inlet
PHYSICAL
Receptacles NEMA5-15R(115V), IEC320 female appliance
coupler(220V)
Battery Back-Up Slow beeping sound
(once per 2 seconds)
Battery Low Rapid beeping sound
(once per 0.5 second)
ALARM
Overload Continue bee
p
in
g
sound
Ambient
operation
3,500 meters max. elevation, 0-95% humidity
non-condensing, 0-40
℃
Audible Noise <40dBA(1 meter from surface)
ENVIRONMENT
Storage
condition
15,000 meters max.
©
2002. July. 29 Version 4.0
All right Reserved. All trademarks are property of their respective owners.
Specifications subject to change without notice.
