GB
6
Digital Calliper
Q
Introduction
Q
Intended use
Only for private use.
Not for commercial use.
Q
Scope of delivery
1 x digital calliper
1 x battery
1 x storage box
1 x instruction for use
Q
Description of parts
1
measuring surfaces
2
internal measuring jaws
3
inch / mm key
4
locking screw
5
LCD display
6
depth-measuring blade
7
handwheel for measuring jaws
8
battery compartment lid
9
key for zero setting (ZERO)
10
ON / OFF key
11
external measuring jaws
Q
Technical data
Measurement unit: mm
Measuring range: 0–150 mm/0–6”
Resolution: 0.01 mm/0.0005”
Accuracy: 0–100 mm ± 0.02 mm/0.001”
100–150 mm ± 0.03 mm/
0.001”
Maximum measuring speed: 1.5 m/s, 60”/s
Measuring system: Liner capacitive measuring system
Display: LCD display
Operating temperature: +5 °C – +40 °C
Influence of humidity: within a range from 0 % to 80 %
relative humidity irrelevant
Battery: 3 V CR2032 (included)
79033_PL-HU-CZ-SK_Content.indd 6 20/09/2012 10:23:34
