▲ 8. Your gate system is required to have a primary and a secondary
entrapment safety system installed and maintained.
▲ 9. If your gate closes automatically, loop detectors should be installed
to detect the presence of a vehicle.
▲ 10. DO NOT increase force adjustment to compensate for a damaged
gate. The gate should always be maintained to operate manually as
easily as possible to provide maximum protection.
▲ 11. Check all safety systems at least once per month for the correct
force, speed and sensitivity. Gate must reverse when hitting a rigid
object, or when a non-contact sensor is activated. If these functions
are observed to operate improperly, discontinue use and have it
serviced immediately!
▲ 12. You are responsible for ensuring that warning signs are installed
and maintained on both sides of your gate.
▲ 13. To ensure safe operation of this equipment, you must read this
safety manual and keep it for reference.
MANUAL DISCONNECT OPERATION
▲ Your operator is equipped with a pad lockable emergency disconnect for
manual operation. Be sure you have a key and understand how to
operate this equipment. To disengage operator, move red disconnect
lever to the left and latch it in place.
▲ WARNING: NEVER OPERATE THE MANUAL RELEASE WHEN THE
GATE IS MOVING.
To Re-Engage Drive:
Lift Lever To Unlatch,
Then Move Lever To
The Right.
To Disconnect Drive:
Move Lever To The Left Until
It Latches In Retaining
Bracket.
Padlock
Option Hole
Retaining
Bracket
Disconnect
Lever
