INSTALLATION INSTRUCTIONS
▲ WARNING: DO NOT APPLY POWER UNTIL TOLD TO DO SO!
RISK OF ELECTRICAL SHOCK OR INJURY MAY
RESULT!
BEFORE INSTALLING OPERATOR
IMPORTANT: Operator should always be mounted inside the gate.
Determine whether the installation is Left hand or Right hand by the
direction the gate moves in order to open, when viewed from inside
the fence.
RIGHT HAND
PUBLIC AREA
OR STREET
LEFT HAND
PUBLIC AREA
OR STREET
1. Gate must slide freely to fully opened and fully closed position.
2. Gate and/or extension must extend beyond the position of the
operator. The operator will be located as shown above, for left and
right hand installation.
