7Questions? Call Toll Free at 1-800-737-2112 Copyright © 2012 MAT Engine Technologies, LLC
Assembly
• Save all instructions
If you need assistance or find any parts missing, CALL
TOLL FREE: 1-800-737-2112.
Read and follow the assembly instructions. Do not discard any parts or materials until the unit is assembled.
References to the right or left side of the tiller are from the viewpoint of the operator’s position behind the tiller.
WARNING
Do not operate tiller if it is damaged or not completely and correctly assembled.
WARNING
Before doing any assembly or maintenance to the unit, remove the wire from the spark plug.
WARNING
Always wear ANSI compliant safety glasses with side shields while assembling the tiller.
The following components will be found in the carton.
Quantities shown in ( ).
1. (1) Tiller
2. (1)UpperHandleAssembly
3. (1)LowerHandle
4. (4) Tines
5. (2) Wheels
6. (1) Drag bar
7. (2) Outside Tine Shields
8. (1) Tiller Operator’s Manual
9. (1) Engine Manual
10. (1) Bottle of Engine Oil
11. (1) Parts bag containing the following
a. (2) Combination wrenches
b.(4)M10x25mmbolts,atwashersforassemblinglowerhandle
c. (4) M8 x 50 mm saddle bolts and washers for assembling upper and lower handles
d.(4)Handleknobs
e.(2)M8x20mmboltsand30mmatwashers for installing wheels
f. (2) M8 x 50 mm bolts and lock nuts for assembling outside tines
g. (2) M10 x 50 mm bolts and lock nuts for assembling inside tines
h. (1) Pin for drag bar
i. (6) M6 x 16 bolts, lock nuts, and washers for installing outside tine shields
1. Remove all parts and packaging components.
2. Use a utility knife to cut all 4 vertical edges and lay the side panels flat around the tiller.
3. Remove any remaining packaging.
How to Remove Tiller from Carton
