Powermate PM3000i - Section 2 General Information and Setup

4 Owner’s Manual for Portable Generator
Section 2 General Information and Setup
Figure 2-1. Features and Controls
Generator Components
Figure 2-2. Control Panel
005678
12
7
16
13
14
9
8
11
010396
15
18
1 Low Oil LED (Yellow)
2 Overload LED (Red)
3 AC Power LED (Green)
4 AC Breaker
5 Grounding Location
6 120V, 20A Receptacle
7 Handle
8 Fuel Tank Cap
9 Control Panel
10 Off/Run/Choke Switch
11 Recoil Starter
12 Muffler
13 Oil Fill/Drain
14 Air Cleaner
15 Carburetor
16 Spark Plug
17 120V, 30A Receptacle (NEMA L5-30R)
18 Spark Arrestor
1 2 3
17
6
4
010477
5
10
4
