Mode
Parameter
Default
Rang Comment
4 3 0
0／1／2／
3
Special Running Mode setup：
0：operator select
1：simple sewing mode
2：calculate initial angle of motor (do not uninstall strap)
3：calculate motor/machine head run rate mode
(synchronizer, do not uninstall strap)
4 4 0 0—31
Torque boost up at low speed :
0：no action
1~31：31 levels Torque boost up
4 5 1 0／1
Stop pin mode：
0：Constant speed tackle mode (in the belt transmission,
Parking is not precision)
1：back pull mode（PMX）
4 6 100 0 ~800
Command button to fill half-needle time
47 150 0 ~800
Command button to fill a needle time
5 0 1 1~100
Stitch counting proportion set up
51 1 1~9999
Stitch counting value set up
5 2 0 0~4
Stitch counting mode selection:
0: no counting
1: Counting up according to stitch number, after reaching set value
then restart.
2: Counting down according to stitch number, after reaching set
value then restart.
3: Counting up according to stitch number, after reaching set value,
then motor should stop automatically, recounting should be restart
by S4 [152.INI] =CRS or the button A on operation panel.
4: Counting down according to stitch number, after reaching set
value, motor should stop automatically, recounting should be restart
by S4 [152.INI] =CRS or the button A on operation panel.
5 3 1 1~100
Trimming counting proportion set up
Count
Mode
5 4 1 1~9999
Trimming counting value set up
