Item Part Qty Description Item Part Qty Description
1 1 Gasoline engine 45 GB5787-86 4 Flange bolt M6×22
2 15100 1 Frame comp 46 14022 4 Washer
3 15002 2 Bottom rubber A 47 14005 4 Collar
4 15003 2 Bottom rubber B 48 14001 4 Cushion
5 GB6177-86 16 Flange nut M8 49 14004 1 Outlet pipeφ4.5×165
6 GB802-88 4 Flange nut M6 50 14006 2 Tube clip
7 41350 4 Cushion, frame 51 14003 1 Rubber, fuel tube
8 GB5787-86 24 Bolt M6×12 52 14100 1 Fuel cock
9 15001 2 Rubber pad, frame 53 13001 1 Protector comp muffler
10 15201 2 Hand push 54 GB5787-86 4 Flange bolt M6×14
11 11010 1 Earth terminal set 55 GB5787-86 2 Flange bolt M8×32
12 GB5787-86 8 Flange bolt M6×12 56 13010 1 Muffler stay
13 11070 1 Receptacles (30A) 57 13020 1 Muffler
14 11073 1 Receptacles (50A) 58 13002 1 Protector muffler inner
15 11072 1 Receptacles (20A) 59 GB5789-86 10 Flange bolt M8×16
16 11120 2 Circuit Breaker 60 13004 1 Seal protector muffler
17 11090 1 Control panel 61 13005 1 Muffler, stay comp
18 11110 2 Voltmeter 62 13003 1 Protector muffler side
19 11050 2 Diode assay 63 11091 1 Control panel case
20 11082 1 Engine switch 64 11101 2 DC output post
21 11040 1 Boot, switch wire 65
11105 1 Voltage selection switch
22 11030 1 Boot, main wire harness 66 GB6177-86 2 Flange nut M12
23 11010 1 Boot, AC output wire 67 GB97.1-85 2 Washer φ20
24 11060 1 Wire harness Assy. 68 21040 2 Wheel comp
25 GB5787-86 5 Flange bolt M5×12 69 21020 2 Bracket
26 16004 1 Generator end cover 70 21010 1
Axle
27 GB5789-86 4 Flange bolt M6×200
179 11090 1 Fuse
28 16003 1 Support stand
180 22001 1
Positive wire of battery
29 GB5789-86 1 Bolt M10×1.25×290 181 22002 1 Negative wire of battery
30 GB9701-85 1 Plain washerφ10 182 22005 1 Battery cover
31 GB276-89 1 Bearing 6207-2RS 183 22010 1 Battery
32 16200 1 Rotor comp 184 11070 1 Brush assy.
33 16000 1 Stator & Rotor Assy. 185 11080 1 Voltage regulator
34 16005 1 Generator fan 186
15010 1
Protector frame side
35 16101 1 Stator cover 187 15011 2 Frame cover
36 16100 1 Stator Assy. 188 15102 1
Frame comp
，
side
37 14201 1 Stripe, fuel tank 189 21012 1
Lining
38 14200 1 Fuel tank 190
15012 1
Protector panel side
39 14302 1 Fuel filter 191
15013 1
Protector Battery side
40 14303 1 Packing ring 192
11193 1 AC protector
41 14300 1 Fuel filler cap comp 193
11195 1 DC protector (10A)
42 14400 1 Fuel sensor 194 11071 1 Receptacles (30A)
43 GB 819-95 2 Screw M5×10
44 14410 1 Casket fuel tank
