Powersmart DB2321C - Knowing Your Lawn Mower

KNOWING YOUR LAWN MOWER
Please use the illustration below to familiarize yourself with the location and function of the components
that control of your lawn mower.
1 Recoil Starter handle 7 Cutting height adjustment lever
2 Cutting height adjustment lever 8
Primer bulb
3 Rear wheel 9 Lower handle
4 Side discharge chute 10 Upper handle
5 Oil dipstick 11 Engine start/stop control
6 Front wheel 12 Gas tank cap
11 10 9
4 5 6 7
12
8
1
2
3
